MTK META Utility V50 :
I
noticed some people corrupted UFS_LU0/EMMC_BOOT1 while trying to exit
brom by other tools [They're writing preloader to offset 0x0 instead of
(0x1000/0x800)] - WRONG, here is the solution to Exit BootROM for this
type.
- Added ability to write (EMMC BOOT1/UFS LU0) via BootROM.
-
If you tried to write it as memory using SPFT, you will get (status sec
write data not allowed (0xC002000C), but now you can write it easily
with MTK META Utility.
-
Note : you can write LU1/BOOT2 instead of LU0/BOOT1, it's just a second
copy of the preloader (Backup region) same as (A/B) Fs - needed for
this cases.
- Increased USB wait timeout to 400000 milliseconds (6.5 minutes).
Do you guys need force brom from Download Mode for these devices? Or it's too old :
- Samsung Galaxy J7+ - MT6757
- Samsung Galaxy J7 Max - MT6757
- Samsung Galaxy On Max - MT6757
- Samsung Grand Prime+ - MT6737T
- Samsung Galaxy J2 Ace - MT6737T
- Samsung Galaxy J2 Prime - MT6737T
- Samsung Galaxy C7 (2017) - MT6757
- Samsung Galaxy J7 Max - SM-G615F - MT6757
- Samsung Galaxy Grand Prime Plus - SM-G532F - MT6737T
$ - This software is provided 'as-is', without any express or implied warranty.
In no event will the authors be held liable for any damages arising from the use of this software.
- USE it at your own risk.
Description
MTKMETAUtility
- Added convert pgpt.bin & Raw eMMC Dump Bin to virtual scatter.
- you need to modify the chipset name + project ID inside the scatter in order to be able to load it into flash sw’s.
- OFP Extractor Now support both (QLM & MTK) firmware extract.
- Added OFP multi super.xx.bin auto combine according to available regions from csv map.
- Added MTK DA Parser to show the list of supported chipsets inside the Download Agent file.
- Added
MTK (Preloader/eMMC Boot1, UFS LU0, Bloader Info, RAw emi data) Parser
to show the list of supported eMMC & UFS flash ID’s inside the
preloader file.
and read (eMMC/UFS id’s info , type,ram,etc). - Supported Bloader Info versions:
MTK_BLOADER_INFO_v08,v10,v11,v12,v13,v14,v15,v16,v17,v20
,v21,v22,v24,v25,v27,v28,v30,v31,v32,v35,v36,v38,v39,v40,v45
,v46,v47,v49,v51,v52,v54
Next version will add :
** ONEPLUS QCOM .OPS extract.
** LG MTK KDZ extract.
** Nokia NB0 extract.
** OZIP extract.
** Samsung UNISOC Rom extract.
